In this blog post, we will show you how to generate and send OpenTelemetry data to Amazon Web Services S3 using Odigos.
Since version v0.1.46, Odigos supports sending OpenTelemetry data to AWS S3. For the first time, you can use S3 to store your OpenTelemetry data, and build custom solutions on top of it.
First, you need to create an S3 bucket. You can do it using the AWS Console or using the aws command line tool. For example, to create a bucket named otel-data in the us-east-1 region, run the following command:
aws s3api create-bucket \
--bucket otel-data \
--region us-east-1
Next, you need to create an EKS cluster. You can do it using the AWS Console or using the eksctl command line tool. For example, to create a cluster named otel-cluster in the us-east-1 region, run the following command:
eksctl create cluster \
--name otel-cluster \
--region us-east-1 \
--version 1.24 \
--nodegroup-name standard-workers \
--node-type t3.medium \
--nodes 3 \
--nodes-min 1 \
--nodes-max 4 \
--managed
eksctl utils associate-iam-oidc-provider --region=us-east-1 --cluster=otel-cluster --approve
For this demo, we will use the emojivoto application. You can install it by running the following command:
kubectl apply -k github.com/keyval-dev/opentelemetry-go-instrumentation/docs/getting-started/emojivoto
After installing the demo application, you need to install Odigos to send data to S3. The simplest way to install Odigos is via the helm chart by executing the following commands:
helm repo add odigos https://keyval-dev.github.io/odigos-charts/
helm install my-odigos odigos/odigos --namespace odigos-system --create-namespace
In order to send data to S3, Odigos needs to have the right permissions. Create a new IAM policy named odigos-s3 with the following content:
{
"Version": "2012-10-17",
"Statement": [
{
"Effect": "Allow",
"Action": [
"s3:PutObject",
"s3:PutObjectAcl",
"s3:GetObject",
"s3:GetObjectAcl",
"s3:DeleteObject"
],
"Resource": ["arn:aws:s3:::otel-data", "arn:aws:s3:::otel-data/*"]
}
]
}
Next, you need to configure the IAM role to be used by Odigos. You can do it by creating a service account and attaching the IAM role to it (replace the account ID with your own):
eksctl create iamserviceaccount \
--name default \
--namespace odigos-system \
--cluster otel-cluster \
--attach-policy-arn arn:aws:iam::123456789012:policy/odigos-s3 \
--override-existing-serviceaccounts \
--region=us-east-1 \
--approve
The last step is to configure Odigos to send data to S3. This can be done easily by accessing the Odigos UI and creating a new AWS S3 destination. Make sure to specify the bucket name you created earlier.
In this blog post, we showed you how to send OpenTelemetry data to AWS S3 using Odigos, an open-source observability control plane. Odigos supports more that 20 different destinations, including cloud providers like Azure and Google Cloud, as well as open-source solutions like Loki, Elasticsearch, and Prometheus.
